DESCRIPTION

Basic Info

Model NO.	LW-VA
Sleeve Material	Ceramic
Connector Gender	Sc Male to Female
Attenuation Accura	±10%
Return Loss	≥50dB
Color	Silver
Keywords	Variable Inline Optical Attenuator
Product Name	Variable Inline LC Upc Sm Fiber Optical Attenuator
Transport Package	Carton
Specification	Male to Female
Trademark	LIGHTWIT
Origin	China
HS Code	8517699000
Production Capacity	500000PCS/Month

Product Description

High quality Variable Inline LC UPC SM Fiber Optical Attenuator

Product Description

LC UPC single mode fiber attenuators are commonly used in fiber optic communications to the the power level of a fiber cable by controlling the amount of signal loss that is passed through the signal. ST single mode fiber optic attenuators can also be used on a more permanent basis in order to match the signal with a transmitter and receiver's specific power levels.Commonly used attenuation range is from 1dB to 20dB.



Features:
High precise attenuation value from 1~30dB
Low insertion loss and high return loss
Perfect environmental stability and reliability
High-power light source durability
Easy installation
Comply with IEC standards
RoHS compliant

Application:
Fiber optical telecommunication system
Optical transmission system
FTTH, CATV, WAN, fiber optical sensor
Metropolitan area network.



Product Specification

Item		Parameter
Model		Fixed, Female&Male, In-line, Variable
Operating Wavelength		SM 1310nm/1550nm
Attenuation Range		1~30dB
Return Loss		APC: ≥60db UPC: ≥55dB PC:≥50dB
Attenuation Tolerance		≤+/-0.5(1-10dB) or ≤+/-1.0(11-30dB)
Maximum Optical Input Power		1000mW
Polarization Dependent Loss		≤0.1dB
Operation Temperature		-40°C~+60°C
Storage Temperature		-45°C~+ 85°C
Humidity		95%RH
