DESCRIPTION

Basic Info

Application	Communication
Type	2 to 24 Cores
Connection Structure	MPO/MTP
Material Shape	Ribbon Cable, Mini Round Cable
Allowed Lateral Pressure	100(N/100mm)<1000(N/100mm)
Allowed Tensile Strength	100N<1000N
Core	Multicore
Certification	RoHS, ISO9001
Brand	ODM
Sheath Material	PVC.LSZH
IEC 61754-7 Compliant	Compact Design, up to 24 Fiber Ribbon
Cable Jacket Color	Blue,Green,Aqua,Red,Magenta,Beige
Adapter Type	MPO
Channel	2 RO 24
Housing Color	Aqua,Green, Beige,Yellow, Magenta
Boot Color	Black
Boot Type	Round, Flat
Polishing	APC, PC
Cable Jacket Material	PVC, LSZH, Ofnr, Ofnp, PE
Transport Package	Single Pack
Specification	CE, RoSH, SGS
Trademark	KOC
Origin	Made in Shenzhen China
HS Code	85447000
Production Capacity	500/Prt Month

Product Description

With 21 years history, KOC is a well-established brand popularly accepted in the world-wide market, especially in European and American countries. We are a professional manufacturer of most passive parts such as patch-cord, connector, adapter, attenuator,splitter, WDM serious. For more detail, please check on our website kocchina.en.made-in-china.com. In case of need, please do not hesitate in contacting us.
MPO Optical Patch-Cord
KOC MPO solution is designed for high-density fber connections and high-speed data center cabling. We provide an economic highly reliable solution for your fber network systems.
APPLICATIONS:- CATV, and Multimedia- Gigabit Ethernet - Industrial and medical - Active device interface- Premise installations- Interconnection for O/E modules - Data processing networks- Telecommunication networks- Optical switch interframe connection- Asynchronous Transmission Mode (ATM)
FEATURES:- IEC 61754-7 Compliant- Compact design, up to 24 fiber ribbon - Polishing does not require diamond film- Precision molded MT ferrule- Telcordia GR-1435-CORE compliant- Low insertion loss and back reflection loss- High precision guide pins for exact alignment

SPECIFICATIONS

	Single mode	Multimode
Insertion Loss	Low Los ≤ 0.35dB	Low Los ≤ 0.35dB
	Standard Loss ≤ 0.7dB	Standard Loss ≤ 0.5dB
Return Loss	≥ 55dB	≥ 30dB
Durability	<0.3dB typical change, 200 matings	-
Operating Temperature	-40 to +85 ºC	-40 to +85 ºC

Note: The price range is for MPO(female)-MPO(female) OM5 12 core mini round cable 10m.(standard insertion loss)
